Cars come in all different shapes, most in the same size; compact. So, we’ve engineered these mini Picasso’s to fit in virtually any location in your ride. Other sport compact amplifiers use bizarre technologies with pseudo power supplies. Picasso Nano’s use tried and tested MOSFET power supplies & tenacious Class D circuitry.

• High Efficiency Class D Monoblock Amplifier
• 1-ohm Minimum Impedance Stable Monoblock Amplifier
• Compact 5.00” Wide Chassis Design for Installation Versatility
• Hybrid Aluminum Alloy Heatsink for Optimum Heat Dissipation
• MOSFET Power Supply w/ Audiophile Grade IRTM Transistors
• Military Grade SMT PCB Maintains Dynamic Performance
• Top-Mounted Pre-Amp Controls Easily Adjustable After Installation
• Top-Mounted Operation Status, Protection, & Clipping Indicators
• Datalink to Strap 2 Like-Monoblocks Together for Double-The-Fun
• Direct Short, Thermal, & Overload Circuits Protect Amplifier
• 200mV-8V Low-Level Audio Signal Input by RCA Interconnect
• High Level / Speaker Level Audio Signal Input w/ Auto Turn-on
• Direct Connect Power/Ground and Speaker Output Terminals
• Variable 12dB High-Pass, Low-Pass, & Band-Pass Crossovers
• 12dB 45Hz Bass Boost Increases Low Octave Harmonics
• Dash Mount Remote Gain Control Module Included
• Max Power 3000W
• RMS Power 2 Ohms 450W
• RMS Power 1 Ohm 800W
• Dimensions 9" x 4.75" x 1.5"
