This DLP projector is a stylish, feature-packed projector ideal for the dedicated home theater or any viewing room in the home. Utilizing DLP technology from Texas Instruments and with a resolution of 854 x 480, the DT-100 boasts a 2500:1 contrast ratio and a brightness rating of 1000 ANSI lumens, delivering one of the best values available in consumer home theater projectors today.

Features



DLP Technology

Texas Instruments Single Chip Digital Micromirror Device (DMD) leads to superior image quality.


High Contrast Ratio 2500:1

enhances the ability to discern fine, detailed differences between the darkest and lightest colors and provides superior black level reproduction.


1000 ANSI Lumens

a high ANSI lumens rating which allows for bright onscreen images even with ambient light.


Native WVGA (854 x 480)

resolution that is high definition compatible.


6 Segment 5X Speed Color Wheel

achieves flicker free, high-grade images with accurate color reproduction.


Sealed Optics

the optical mechanism of this DLP projector is sealed in its structure, preventing dust, dirt and smoke from entering the core components of the optics.
Specifications




HDTV Compatible 1080i, 1035i, 720p, 576p, 540p, 480p, 480i




Aspect Ratio 4:3/16:9




Resolution 854 x 480 (WVGA)




Brightness 1000 ANSI Lumens




Contrast Ratio 2500:1




Component Inputs HD-15 (RGB) Component (x2)




Anamorphic DVD Capable Yes




Maximum Screen Size 40" - 300" (diagonally measured)




Projection Distance 100" 16:9 Screen Throw Distance
11' 7" - 13' 5"




Display Method Single Chip Digital Micromirror Device (DMD) by Texas Instruments




DMD Panel Panel size: 0.53", 1 chip DMD
Number of dots: 409,920 dots
(854 H x 480 V)




Computer Compatibility SXGA+, SXGA, Mac 21"/19"/16" (In intelligent compression), WVGA,VGA,
PC-98, VESA, Mac 13"




Video System NTSC3.58//NTSC4.43/PAL/PAL-M/
PAL-N/PAL60/SECAM/DTV480I/DTV480P/
DTV540P/DTV576I/DTV576P/DTV720P/
DTV1035I/DTV1080I/DTV1080I-50




Lens Type 1-1.15 X zoom lens,
F2.4-2.6, f = 19.0-21.9 mm




Projection Lamp Type 275W SHP




Lamp Life up to 3,000 Hours (Eco Mode)




Fan Noise 30 dB (in Eco Mode)




Inputs 2 Computer RGB/Component (15-pin mini D-sub)
1 Composite Video (RCA)
1 S-Video (4-Pin DIN)
1 RS - 232 C
1 Audio Input (PC) 3.5 Mini Jack
1 Audio Input (Video) RCA




Outputs 1 HD-15 (RGB) Component
1 Audio (PC) 3.5 Mini Jack




Built-in Audio Yes, 2W (Mono)




Digital Keystone Correction Yes (Vertical)




Color Temperature Adjustment Yes




Detachable AC Cord Yes




Wireless Light-Up Remote Control Yes




Optional Digital Decoder Required Yes (for HDTV)




Optional
Ceiling
Bracket Yes, Model Number: AN-XRCM30




Power Source 100-240V AC, 50/60Hz (Multi-Voltage)




Power Consumption 350W (4W Standby)




Dimensions
(w x h x d) 12-13/32" x 4-19/64" x 11-1/32"
(main body only)
12-13/32" x 4-47/64" x 11-37/64"
(including adjustment foot and projecting parts)
