FEATURES
Remote diagnostics (IP-ready with optional Ethernet card)
Ground Isolation - Advanced Video Filtration Voltage regulation and Balanced Power
Automatic Voltage Monitoring (AVM)
Satellite (SAT) and Cable Access Television (CATV) protection
Telephone (TEL) and Local Area Network (LAN) protection
WARRANTIES
$5,000,000 Connected Equipment Protection Policy
Panamax will protect your equipment or we will repair or replace up to $5,000,000!
3 Year Product Warranty
The surge protector shall be free of any defects in design, materials, or workmanship, and Panamax will repair or replace any defective product up to three years from the purchase date.

AC SPECIFICATIONS
Protect or Disconnect Circuitry Yes
Thermal Fusing Yes
Catastrophic Surge Circuit Yes
Single Pulse Energy Dissipation 2670 Joules
Spike Capacity 162,000A
EMI/RFI Noise Filtration 100dB (100kHz-2MHz)
Line Voltage 120VAC, 60 Hz
Clamping Level (TVSS Voltage) 330V
Initial Clamping Level 200V
Overvoltage Shutoff 142V+/-5V
Undervoltage Shutoff 90V+/-2V
Protection Modes L-N, N-G, L-G
Maximum Current Rating 15A (1800W)
Response Time <1ns

PRODUCT FEATURES
Number of Outlets 11
Always On Outlets up to 11
Switched Outlets 4
Delayed Outlets up to 6
Cord Length 10 ft.
Connections Straight
Length 12.75"
Width 17"
Height 3.5"
Weight 36 lbs.


TELCO SPECIFICATIONS
SignalPerfect Circuitry
Fuseless / Auto Resettable Yes
Clamping Level 260v Telco/ 8v LAN
Capacitance 30pf (approx.)
Suppression Modes Metallic & Longitudinal
Wires Protected Pins 4,5 Telco (1 In 2 Out)/ Pins 1, 2, 3, & 6 LAN
Connectors Tel RJ-11, LAN RJ45

AGENCY & WARRANTY
Agency Approval
Product Warranty Length 3 Years
Connected Equipment Policy Length Lifetime
Connected Equipment Policy Amount $5,000,000
Lightning Protection Yes


COAX SPECIFICATIONS
Antenna/Cable Lines Protected 2
Antenna/Cable Clamping 1.4V
Antenna/Cable Attenuation <1 dB up to 950 MHz
Satellite Lines Protected 2
Satellite Clamping 25V
Satellite Attenuation <1 dB from 950MHz-2.05GHz, <2.4 dB @ 2.2GHz
Coax Connectors Female
