CEDIA Special until Sept 5th 2009!!
Number of channels: five (5) discrete monaural blocks
Power rating per channel (8-ohm load), all channels driven: 300 watts. (4-ohm load), all channels driven: 600 watts. (2-ohm load), all channels driven: 1000 watts
Frequency response measured at 1 watt with +/-0.1 dB: 20 Hz to 20 kHz
Channel separation: greater than 95 dB
Maximum input voltage: 1.9 volts
NOW with Balanced XLR inputs
Input impedance: 27,000 ohms
Total harmonic distortion -THD: 1 kHz, 8-ohm load: 0.001%. 20 kHz, 8-ohm load: 0.003%. 1 kHz, 4-ohm load: 0.003%. 20 kHz, 4-ohm load: 0.006%. 1 kHz, 2-ohm load: 0.005%. 20 kHz, 2-ohm load: 0.006%
Signal to noise ratio: @ 1 kHz, 112 dB @ 5 kHz, 111 dB @ 10 kHz, 110 dB
High-pass / low pass variable filter, range 20 Hz to 5 kHz (one/ channel)
High-pass/Full range/Low pass operation via 3-way switches (one switch per channel).
Dimensions: 9.25" x 18" x 21" (height x width x depth)
Gross Weight : 141 lbs
