Model: ES-062i GOLD - $799.00
The ES-06 Extended bass woofer used in this system has a slightly more massive voice coil than typical bass/midrange and leans toward the bass in the sound compared to the classic 6.5" type. The cone is made of mixed Fiberglass Kevlar fabric. The upper midrange is somewhat mellower than the classic type 6.5". Response is fast tight and power full and very smooth.
The result is astounding naturalness and precision. The measurements show smooth extension and glitch-free roll-off.
The soft dome Euro tweeter has the classic dome shape and an ultra smooth response shape. This tweeter with its excellent power handling ability is further cultured by the matching crossover that corrects the smoothly sloped response shape and corrects that shape.
This improved shape is flatter and more extended as a result thereby giving the power handling benefit of a larger soft dome with the power response profile of a lower power handling 19 mm size driver.
This improved shape is flatter and more extended as a result thereby giving the power handling benefit of a larger soft dome with the power response profile of a lower power handling 19 mm size driver. This is critical to natural airy sound yet with authority .
The two drivers are then also interfaced with each other with a proprietary crossover using an elliptical high-pass characteristic. This type of filter utilizes intra circuit phase relationships to produce rapid response changes. Within a narrow band signal cancellation by subtraction occurs allowing a rapid response roll-off without the attendant transient response smear and complexity of conventional high order filters.

Specs for Model: ES-062i GOLD
Model: ES-062i GOLD (6.5" 2-way)
-Extended bass mid woofer: 6.5" Cast
-Crossover: EX-560iTransient Optimized Elliptic 4th order 2-way
-Tweeter: DRT-26 extended range modular 1 silk tweeter. aluminum and titanium twtr drivers available
-Power handling: 250 watt RMS @ 100Hz High Pass
-Frequency response: 50-20kHz
-Sensitivity: 90.3dB.
-Impedance: 4 Ohm
Surface & flush mount tweeter
